KYN28A-24(GZS1) MV Switchgear Fittings - Earthing Switch Interlocking Device, 5VACY.363.010-246( in 24kV Cabinet, Middle Interlocking Device)

Specification Code:5VACY.363.010-243

Specification Description:middle interlocking device

Earthing switch interlocking device in 24kV cabinet

(middle interlocking device)5VACY.363.010-243

Instruction:
    This interlock device is only used for middle installation of earthing switch, if need to install in the back, please use 5VACY.363.010-241/242. The back shaft of this scheme is insulation, which doesn't need to consider the clearance of earth from busbar to operating shaft, and greatly improve the relibility and security. lt also has the backdoor
anti-locking function.The strength is same as 5VACY.363.010.3.
