KYN28A-12(GZS1) MV Switchgear Fittings - Second Socket with 58 Cores

Specification Description:Secondary socket with 58 cores

Secondary socket

Application:
GZD-58 secondary socket is used for secondary circuit connection of GZS1 (matched withVS1, VD4)etc. high voltage intermediate switchgear.

Basic parameter:
Rated voltage :AC 380V ,DC220V , rated current: AC 16A ,DC10A ,mechanical life : 2000times.

Note:the socket is equipped with pin ,the wiring hole can only use wire below 1.5mm2. Please specify if you need 2.5 or 4mm 2wire.
