KYN28A-12(GZS1) MV Switchgear Fittings - New Emergency Opening Device, 5VACY.1505.2000

Specification Code:5VACY.1505.2000

New emergency opening device 5VACY.1505.2000

    The products are mainly used in switching cabinets to simplify the operation of the circuit breaker tripped procedures, improve processing speed of emergency circuit of sudden failure. The product uses rotary folded structure allows a manual trip in test position and work position without opening the door, and the mechanism can be operated with one hand,(let go can automatically reset),and therefore easy to operate with fast speed.
